The SINAMICS G120 PM240-2 Power Supply Module is a highly efficient component featuring an integrated Class A filter and a braking chopper. Designed to operate at a voltage range of 3AC 380-480V with a tolerance of +10/-20%, this module is suitable for a frequency range of 47-63Hz. It is capable of handling significant overloads, providing up to 30KW for 200% overload for short durations of 3 seconds, 150% for 57 seconds, and 100% for 240 seconds, all while maintaining ambient temperatures from -20°C to +50°C.
In scenarios where lower overload capacities are required, the PM240-2 can manage up to 37KW for 150% overload for 3 seconds, 110% for 57 seconds, and 100% for 240 seconds, with an ambient temperature range of -20°C to +40°C. The dimensions of the module measure 472 x 200 x 237 mm (H x W x D), and it has an IP20 protection rating. Please note that this product does not come with a control unit or panel and is approved for CU firmware version V4.7 HF8.
- Integrated Class A filter
- Braking chopper included
- Voltage range: 3AC 380-480V (+10/-20%)
- Frequency: 47-63Hz
- High overload capacity: 30KW for 200% (3s), 150% (57s), 100% (240s)
- Low overload capacity: 37KW for 150% (3s), 110% (57s), 100% (240s)
- Ambient temperature: -20°C to +50°C (high), -20°C to +40°C (low)
- Dimensions: 472 x 200 x 237 mm (H x W x D)
- Protection class: IP20
This power supply module is manufactured by SS Industrials, ensuring high quality and reliability. It comes in its original packaging, factory-sealed to guarantee its integrity. The module is compact, measuring just 20 x 20 x 30 cm, and weighs only 2 KG, making it easy to handle and install.
Purchasing this unit provides peace of mind with a full warranty of one year and reliable after-sales service. The product is readily available in stock, with a swift delivery timeline of 1-3 days following payment confirmation. It can be shipped via multiple reliable carriers, including DHL, FedEx, EMS, UPS, and TNT.
