Allen-Bradley 20BP140A0AYNANC0 PowerFlex 700 AC Drive 140A 75HP Specifications

The PowerFlex 700 AC Drive from Allen-Bradley is engineered for efficiency, boasting a robust performance of 140 Amps and a power capacity of up to 75 HP. This drive operates at a voltage of 540 VDC and supports normal duty applications, making it an excellent choice for various industrial needs. With an IP20 / Type 1 rating, it is suitable for indoor environments where protection from dust and moisture is necessary.

Designed without a Human Interface Module (HIM), this model features a blank plate, which allows for straightforward integration into existing setups. It does not include a brake IGBT or a drive-mounted brake resistor, ensuring a streamlined design. Compliance with the CE EMC directive (89/336/EEC) is guaranteed through its second environment filter, promoting reliable performance.

The PowerFlex 700 drive is equipped with vector control technology, providing precise control over motor functions, and features 24V I/O capabilities. However, it does not support feedback mechanisms or additional communication modules, making it a focused solution for applications requiring minimal complexity.

• Voltage: 540 VDC
• Current: 140 Amps
• Power Rating: 75 HP (Normal Duty), 55 HP (Heavy Duty)
• Protection Rating: IP20 / Type 1
• HIM: No (Blank Plate)
• Brake IGBT: Not included
• Drive Mounted Brake Resistor: Absent
• Environment Filter: Second Environment Filter (CE EMC directive compliance)
• Communication Module: None
• Control Type: Vector Control with 24V I/O
• Feedback: Not available
