ABB PM564-RP-ETH-AC 3ABD00033171 Processor Module

The PM564-RP-ETH-AC processor module from ABB is a versatile component designed for efficient control and automation tasks. With its robust specifications, it offers a comprehensive solution for various industrial applications. This module features 128KB of program memory, making it suitable for managing complex processes while ensuring reliability.

Equipped with 8 digital inputs, 6 relay outputs, 2 analog inputs, and 1 analog output, this processor module provides extensive connectivity options. The COM1 interface supports a Sub-D 9-hole RS485 connection, allowing it to operate with free protocols, ModbusRTU in both master and slave modes, or CS31 as a master. Additionally, there is an optional COM2 port for further expansion.

One of the standout features of the PM564-RP-ETH-AC is its integrated Ethernet interface, which facilitates seamless communication within networked environments. This capability is essential for modern industrial settings where data exchange and remote monitoring are crucial. The module operates on a power supply voltage range of 100-240V AC, ensuring compatibility with various electrical systems.

• 128KB program memory
• 8 digital inputs (DI)
• 6 relay outputs (DO)
• 2 analog inputs (AI)
• 1 analog output (AO)
• COM1: Sub-D 9-hole RS485 interface, configurable for free protocol, ModbusRTU (master/slave), or CS31 (master)
• Optional COM2 port
• Integrated Ethernet interface
• Power supply: 100-240V AC
