ABB PM554-TP-ETH 3ABD00033168 CPU Module

The PM554-TP-ETH CPU module is designed for enhanced performance and flexibility in automation tasks. It features a robust 128KB of program memory, making it suitable for various control applications. This module includes 8 digital inputs and 6 digital outputs (transistor type), providing versatile connectivity options for various systems.

Equipped with a COM1 interface, the PM554-TP-ETH supports a SUB-D 9-hole RS485 connection, allowing for various communication protocols. Users can choose between free protocol, Modbus RTU (in both master and slave configurations), or CS31 for advanced control scenarios. Additionally, there is an optional COM2 port for added connectivity, and an integrated Ethernet interface ensures seamless network integration.

This CPU module operates at a power supply voltage of 24V DC, making it efficient for industrial applications. With its combination of features, the PM554-TP-ETH is a reliable choice for those looking to enhance their automation systems with advanced control capabilities.

• 128KB program memory
• 8 digital inputs (DI)
• 6 digital outputs (DO, transistor type)
• COM1: SUB-D 9-hole RS485 interface
• Supports free protocol / Modbus RTU (master/slave) / CS31 (master)
• Optional COM2 port
• Integrated Ethernet interface
• Power supply voltage: 24V DC
